Alpha 500K Reverse Audio Taper Pot, Left Handed, 3/4″ Bushing, Split-Shaft

Sale!
Alpha 500K Reverse Audio Taper Pot, Left Handed, 3/4" Bushing, Split-Shaft

Alpha 500K Reverse Audio Taper Pot, Left Handed, 3/4″ Bushing, Split-Shaft

Original price was: $3.99.Current price is: $3.10.

20 in stock

SKU: WDPLH-500XL-1 Categories: ,

Description

Alpha 500k reverse audio taper pot with hardware. Often used for controls on left-handed instruments Stamped “WD500XLR” on the back of the housing. Long-shaft potentiometers like these are commonly used when wiring carved top solid body guitars.

Specifications

  • Resistance: 500k
  • Body Diameter: 24mm
  • Taper: Reverse Audio
  • Bushing Threads: 3/8-32
  • Bushing Length: 3/4″
  • Bushing Material: Brass
  • Shaft Style: Split-Shaft (Fine Spline 24 Tooth)
  • Shaft Material: Aluminum

Professional installation is strongly recommended. Improper installation may result in damage to the product and/or instrument.
