Kluson KHBSG Harmonica Tuneomatic Bridge w. Studs and Inserts – Gold

Sale!
Kluson KHBSG Harmonica Tuneomatic Bridge w. Studs and Inserts - Gold

Kluson KHBSG Harmonica Tuneomatic Bridge w. Studs and Inserts – Gold

Original price was: $183.99.Current price is: $139.95.

70 in stock

SKU: KHBSG Categories: , ,

Description

This bridge, popularly referred to as the harmonica bridge is a direct replication of the original using all the same quality fabrication, dimensions and best of all, milled from steel billet to give you the tone you crave. A proper replacement for all those vintage Gibson® guitars with no modifications neccessary. Studs and inserts included.

Specifications:

  • Bridge Dimensions = 3.5 in. L X 1 in. W X 25/64 in. at center
  • E to E String Spacing = 52mm
  • String Pitch = 10.4mm
  • Radius = 12 inch
  • Material = Billet Steel w/ brass saddles
  • Stud thread = 8mm X 1.25 pitch
  • Spacing Center to Center = 2 7/8 in. (73mm)
  • Stud top diameter = 4.7mm
  • Stud base diameter = 9.5mm
  • Inserts included

Kluson SKU: KHBSG

Professional installation is strongly recommended. Improper installation may result in damage to the product and/or instrument.
