The latest generation of Nord’s iconic flagship series – the Nord Stage 4 features a new intuitive panel design, a premium triple sensor keybed, and complete effect sections for each layer. With significant enhancements to our award-winning technologies – the Stage 4 sets a new standard for live performance stage keyboards.
Connections
4 Assignable Audio Outputs – ¼”, 6,35 mm jacks, unbalanced
Stereo Headphone output – ¼”, 6,35 mm stereo jack
1 Monitor input – 1/8″, 3,5 mm stereo jack
Sustain Pedal – ¼”, 6,35 mm jack. Compatible with Nord Sustain Pedal 2 (continuous sensor), Nord Triple Pedal 1 and switch type pedals
Triple Pedal – 5 pin DIN connector. Compatible with Nord Triple Pedal 2
Rotor Pedal – ¼”, 6,35 mm jack.Use a momentary pedal or a switch type pedal.
Organ Swell Pedal – ¼”, 6,35 mm TRS stereo jack.
Control Pedal – ¼”, 6,35 mm TRS stereo jack.
Foot Switch input – ¼”, 6,35 mm jack.Use a momentary two-button pedal or a single switch type pedal.
MIDI In – 5 pin DIN connectors
MIDI Out – 5 pin DIN connectors
USB – type B connector for USB MIDI, Software Update and Sound Transfer
